- Place of Origin: China
- Brand Name: Shandong Aoqi
- Model Number: QUY350
- :
- :
- :
- :
- :
Item | Unit | Data | Remarks | ||
Standard Status
| Boom Status | Max. lifting Capacity | t | 350 | |
Boom length | m | 24~84 | |||
Boom Tower Boom Status | Max .lifting capacity | t | 155 | ||
Max .length of boom and tower boom | m | 150 | 72m 78m | ||
Boom angle | ° | 85,75,65 | |||
Boom Fixed Jib Status | Max .lifting capacity | t | 66 | ||
Max .length of boom and fixed jib | m | 114 | 78m 36m | ||
Fixed jib angle | ° | 10,30 | |||
Light Duty Boom | Max .lifting capacity | t | 87.2 | ||
Light duty boom length | m | 81~96 | |||
Supperlift Status | Boom Status | Max .lifting capacity | t | 350 | |
Boom length | m | 36~90 | |||
Boom Tower Boom Status | Max .lifting capacity | t | 155 | ||
Max .length of boom and tower boom | m | 162 | 84m 78m | ||
Boom angle | ° | 85,75,65 | |||
Boom Fixed Jib Status | Max .lifting capacity | t | 66 | ||
Max .length of boom and fixed jib | m | 120 | 84m 36m | ||
Fixed jib angle | ° | 10,30 | |||
Light Duty Boom | Max .lifting capacity | t | 71.1 | ||
Light duty boom length | m | 96~108 | |||
Working Speed | Travelling speed | Km/h | 0.45~1.2 | ||
Slewing speed | rpm | 1.1 | |||
Main hoisting speed(single rope) | m/min | 135 | |||
Auxiliary hoisting speed(single rope) | m/min | 135 | |||
Main luffing speed(single rope) | m/min | 48*2 | |||
Tower boom luffing speed(single rope) | m/min | 126 | |||
Super-lifting luffing speed(single rope) | m/min | 142 | |||
Engine | Model | (VOLVO)TWD1240VE | |||
Rated power/ tachometer | Kw/rpm | 310/2100 | |||
Max. torque/ tachometer | N.m/rpm | 1719/1500 | |||
Quality Parameter | Total weight(basic boom) | t | 326 | ||
Counterweight pressure weight | t | 350 30 | |||
Ground pressure(standard basic boom) | Mpa | 0.152 | |||
Transport Parameter | Max. transport weight(single part) | t | 76.36 | ||
Max. transport dimension(single part)(L*W*H) | m | 14.455*3.16*3.25 | |||
